Features:

MTR Series is applicable to all types of horizontal injection machine for 50-250T for take-out products and sprues, there are two types of arm, single stage-and telescopic type; vertical stroke:550-850mm,traverse axle can be driven by rodless cylinder or inverter motor, AC servo moto is optional. Vertical and crosswise driven by pneumatic cylinder;t raverse axle and vertical arm are applied with advanced high rigidity linear slide rail, and vertical arm are applied with advanced high rigidity linder rlide rail, and light high rigidity alloy aluminum extrusion beam for crosswise and vertical axles.

Controllers:

*Palm controller with dialogue type operation interface, easy to operate and the display language is changeable.

*Built-in eight groups of standard programs and twenty groups of molding memorizing function. with U/L take our function can be integrated with placing methods, swivel chosen, ejector setting and defect alarming.

*Automatically defecting, displaying and recording the failures.

*LED display important signal, such as safety door, MOP, open/close mold.

*A large LED display provides simple programming and setting of all parameters.

*Middle-plate inspection, spray device, air nipper and safety placing detecting are available to operate with automatic application of the factory.
